Product Introduction

Brand: USR
Model: TEC80
Number of phases: single phase
Start mode: panel remote start, remote start
Maximum power: 8wW
Rated power: 7.3kW



FEATURES

COMFORTABLE CLIMATE WHEN MAINS POWER IS UNAVAILABLE
Travelling off the beaten track with all the comfort you are accustomed to – USR Generators make it possible. They ensure reliable power supply wherever mains power is unavailable. This makes them a must-have accessory for outdoor enthusiasts striving for maximum freedom and independence. Geared to the needs of camping enthusiasts, the TEC 80 petrol generator ensures self-sufficient operation of all USR RV air conditioners. Naturally, it will supply other gadgets too. Outstanding benefits: lightweight, efficient operation with reduced noise and odour emission.

USR TEC 80 is a highly compact and lightweight generator fuelled by regular unleaded petrol. Ideal for fitting under the vehicle floor, it provides 5000 W continuous output and is also extremely efficient, with minimal noise and smell emission. Its convenient auto start function starts the generator to recharge a battery as soon as its voltage becomes low. Like all Dometic generators the TEC 80 is supplied complete with remote control. There's no reason to ever be without power!
SPECIFICATIONS
GENERAL


SKU replaced by 9102900299 ( AM version ) & 9102900304 ( OEM version )
Scope of delivery Generator, control panel + 5mt cable, external silencer + 2mt flexible exhaust pipe, brackets, change over switch, clamps, washers, muffler curve, fuel filter, cut out template, user and installation manuals
Product Description Petrol generator
DIMENSIONS
Dimensions product depth 530 mm
Dimensions product height 365 mm
Dimensions product width  590 mm


Net weight 137 kg
ELECTRICAL
Output voltage 230 V
Output current 32.0 A
PERFORMANCE
Continuous power 25°C 7200.00 W
Operating temperature min -15.00 °C
Operating temperature max 50.00 °C
Fuel type RON 91 Regular Grade Petrol
LOGISTICS
Dimensions parcel depth 600 mm
Dimensions parcel height 760 mm
Dimensions parcel width 750 mm

Parcel weight 147kg


o 230 V AC – just like at home
o Suitable for supplying sensitive electronic devices
o Extra 12 V output for battery charging with auto start function
o 7200 W continuous output
o 8000 W peak output
o Remote control included

o Sound-dampened stainless steel cabinet


Download Brochure TEC80
